Stratix 5100 Device Manager Parameter Definitions
Chapter 4
Packets Sent Every (optional)
The number of seconds between each CDP packet that the device sends. The default
value is 60. This value needs to be less than the packet hold time.
Individual Port Enable
• Ethernet
When selected, the device sends CDP packets through its Ethernet port and
monitors the Ethernet for CDP packets from other devices.
• Access point Radio Options
When selected, the device sends CDP packets through its internal radio port and
monitors the internal radio for CDP packets from other devices.
Note: A MIB file is available for use with CDP. The filename is CISCO-CDP-MIB.my, and
you can download the MIB at
CDP Neighbors Table
This section displays the type of device that is discovered. Specifically, it displays
these values:
• Device ID
The configured ID, MAC address, or serial number of the device.
• Interface
The number and type of the local interface protocol being used.
• Hold time
The number of remaining seconds the current device holds the CDP
advertisement from a transmitting router before discarding it.
• Capability
The device type as listed in the CDP Neighbors table. Possible values are R for
router, T for transparent bridge, B for source-routing bridge, S for switch, H for
host, I for IGMP device, or r for repeater. If you click the calculator image, you see
a popup with the legend of code to capability.
• Platform
The device product number.
• Port ID
The protocol and port number of the device.
Table 46 - CDP Page Parameter Descriptions (Continued)
Parameter
Description
