192 Eos Operations Manual
Introduction to Playback
Eos offers one master fader pair and ten motorized faders with 30 pages of control. You can define,
on a page by page and fader by fader basis, how each of the ten faders will function: as playbacks
for cues, submasters (additive or inhibitive), or as grand masters. There is no default setting for
faders, which allows you the freedom to define each faders’ function in Setup (
Setup, page 83 ) or
you can configure them while programming, as the contents of those targets are stored.
You can page the ten motorized faders using the [Fader Page] button alone, combined with the
numeric keypad, or with the wheel directly below the [Fader Page] button. As pages are changed,
the faders will reset to the last position they were in on the associated page. Also, each individual
fader is provided with a [Load], [Go] and a [Stop/Back] button for operation and playback. These
buttons behave differently when the fader is a submaster or grand master. A playback display is
located directly above the faders and provides information about each fader including the fader
designation (S = submaster with the designation of the submaster number, L = playback with
designation of the cue list and cue number that is loaded, or GM = grand master).
The master playback fader pair is located to the right of the ten fader array, near the control keypad.
The master is a split cross-fader pair. You cannot page the master fader as it is permanently paired
and always available for use. The two buttons beneath the master fader pair are [Go] and [Stop/
Back]. The [Load] button and playback display are located just above the potentiometers.
Playback controls
.
Load buttons
Rate / Fader
page controls
Fader
Control
buttons
Motorized
playback
faders
Master
Fader
Pair
