Model 9110EH Instruction Manual Getting Started
3.6. First Calibration
3.6.1. Basic Calibration Procedure
The initial calibration should be carried out using the 500 ppb range, a span gas with about
400 ppb NO and with the unit set for SINGLE range, which will enable you to compare your
calibration results to the factory calibration as listed on the Final Test and Validation Data
Sheet. The following three-step procedure assumes that the instrument does not have any
of the available zero/span (Z/S) valve options installed. Chapter 7 contains instructions for
calibrating instruments with Z/S valve options, Chapter 8 for EPA protocol calibration.
Set the analog output range of the M200E:
SETUP X.X RANGE CONTROL MENU
MODE SET UNIT EXIT
Press this button to set
the analyzer for SNGL
DUAL or IND ranges
SETUP X.X RANGE: 500.0 CONC
0 0 5 0 0 .0 ENTR EXIT
To change the value of the reporting
range span, change the numbers by
pressing the keys under each digit.
Press this button to select the
concentration units of measure:
PPB, PPM, UGM, MGM
EXIT ignores the new setting and returns
to the RANGE CONTROL MENU. ENTR
accepts the new setting and returns to the
RANGE CONTROL MENU.
SETUP X.X
CFG DAS RNGE PASS CLK MORE EXIT
SAMPLE RANGE = 500.0 PPB NOX= X.X
< TST TST > CAL SETUP
SETUP X.X RANGE: 500.0 Conc
0 0 0 5 0 .0 ENTR EXIT
M9110EH Rev 0 27
