Architecture 873
Offset PAD set 0 PAD set 1
3 4dB -10db
4 5dB 0.6db
5 6.1dB 7db
6 8dB 9db
7 -1dB 10db
8 -3dB 11db
9 -4dB 12db
A idle code, 7F 3db
B unassigned code, FF 14db
C 1dB spare
D -2dB spare
E -5db spare
F -6db spare
D-channel interface
The D-channel interface is a 64 Kbps maximum, full-duplex, serial bit-stream
configured as a DCE device. The data signals include receive data output,
transmit data input, receive clock output, and transmit clock output. The
receive and transmit clocks can vary slightly from each other as determined
by the transmit and receive carrier clocks.
Feature selection through software configuration for the D-channel includes:
• 56 Kbps
• 64 Kbps clear
• 64 Kbps inverted (64 Kbps restricted)
DCHI can be enabled and disabled independent of the PRI card, as long as
the PRI card is inserted in its cabinet slot. The D-channel data link cannot
be established however, unless the PRI loop is enabled.
On the NTAK09 use switch 1 and position 1 to select either the D-channel
feature or the DPNSS feature, as follows:
• OFF = D-channel
• ON = DPNSS (U.K.)
