118 Option settings
Table 61
QPC841 DTE or DCE selection
Port 1—SW8 Port 1—SW9 Mode
1 2 3 4 5 6 1 2 3 4 5 6
DTE (terminal) on on on on on on off off off off off off
DCE (modem) off off off off off off on on on on on on
NT1P61 (Fiber) on off off on off off on off off off on on
Port 2—SW6 Port 2—SW7
DTE on on on on on on off off off off off off
DCE off off off off off off on on on on on on
NT1P61 (Fiber) on off off on off off on off off off on on
Port 3—SW4 Port 3—SW5
DTE on on on on on on off off off off off off
DCE off off off off off off on on on on on on
Port 4—SW2 Port 4—SW3
DTE on on on on on on off off off off off off
DCE off off off off off off on on on on on on
