332 NT5D97 Dual-port DTI2 PRI2 card
Voltage Source Current
DDP2
(without
NTBK51AA)
DDP2
(with
NTBK51AA)
+12V Backplane 25mA 75mA
-12V Backplane 25mA 75mA
Total Power (Maximum) 15.6W 20.8W
Cable requirements
This section lists the types of cable used and the lengths required for
internal and external NT5D97 DDP2 connections.
Note: No additional cabling is required for nB+D configurations. Multiple
DDP2 cards and the D-channel are associated through software in
LD 17.
DDP2 cable assemblies include:
• E1 carrier cables
— NTCK45AA (A0407956)
— NT8D7217 (A0617192)
— NTCK78AA (A0618294)
— NTCK79AA (A0618296)
• DDP2 to QPC471/QPC775 Clock Controller Cables
— NTCG03AA
— NTCG03AB
— NTCG03AC
— NTCG03AD
• DDP2 to DCH cables
— NTCK46AA
— NTCK46AB
— NTCK46AC
— NTCK46AD
• DDP2 to MSDL cables
— NTCK80AA
— NTCK80AB
