Installation and configuration
189
5
Configure the Lineside T1 card through the system software and
verify self-test results.
6
Verify initial T1 operation and configure MMI (optional).
—End—
Steps 1-5 are explained in this section. Step 6 is covered in
Peripheral Signaling card" (page 104)
Installation and configuration of the Lineside T1 card consists of six basic
steps:
Step
Action
1
Configure the dip switches on the Lineside T1 card for the
environment.
2
Install the Lineside T1 card into the selected card slots in the IPE
shelf.
3
Cable from the I/O panel to the Customer Premise Equipment
(CPE) or CSU, MMI terminal or modem (optional), external alarm
(optional), and other Lineside T1 cards for daisy chaining use of
MMI terminal (optional).
4
Configure the MMI terminal.
5
Configure the Lineside T1 card through the Meridian 1 software
and verify self-test results.
6
Verify initial T1 operation and configure MMI (optional).
—End—
Steps 1-5 are explained in this section. Step 6 is covered in
Dip switch settings
Begin the installation and configuration of the Lineside T1 card by selecting
the proper dip switch settings for the environment. The Lineside T1 card
contains two dip switches, each containing eight switch positions. They are
located in the upper right corner of the motherboard circuit card as shown
in
Figure 32 "Lineside T1 card - T1 protocol dip switch locations" (page
. The configuration for these switches are shown in
