QPC513 Enhanced Serial Data Interface card
Synchronous port address space is the same as asynchronous port address
space. When selecting an address for the ESDI card, make sure that it does
not conflict with an address currently being used by an asynchronous card.
Table 447 "ESDI card address switch settings" (page 1098)
shows the ESDI
card address switch settings.
Table 447
ESDI card address switch settings
Device Number
Switch S2
style A
Switch S2
style B
Port 1
Port 2
1
2
3
4
1
2
3
4
0
1
off
off
off
on
off
off
off
*
2
3
on
off
off
on
off
off
on
*
4
5
off
on
off
on
off
on
off
*
6
7
on
on
off
on
off
on
on
*
8
9
off
off
on
on
on
off
off
*
10
11
on
off
on
on
on
off
on
*
12
13
off
on
on
on
on
on
off
*
14
15
on
on
on
on
on
on
on
*
* Switch S2, position 4 is not used on style B cards.
DTE/DCE mode jumper settings
The interface for each ESDI port is configured independently. Ports must be
configured both for electrical interface (RS-232-C or high-speed) and mode
(DTE or DCE). With the proper options set:
•
An ESDI port configured as DTE appears as a terminal to the user
equipment.
•
An ESDI port configured as DCE appears as a modem to the user
equipment.
Interface options are set by installing option jumper plugs into the sockets
indicated in
Table 448 "ESDI card DTE/DCE mode jumper settings" (page
Table 449 "ESDI card RS-232-C/high-speed interface jumper
