Page 80

Acceptance tests

If the system response is other than OK, see Software Input/Output
Reference — Administration (NN43001-611) to analyze the
messages.

End the session in LD 34:

****

Using a maintenance telephone, log into the system.

See "Communicating with the Meridian 1" in the Software
Input/Output Reference — Administration (NN43001-611) for details
on accessing the system using a maintenance telephone.

From the maintenance telephone, enter:

LD#34##

To test outpulsers and channels for the TDS loop, see

Table 12 "TDS

tone tests" (page 80)

for a sample of the input commands used with

the maintenance telephone. See Software Input/Output Reference
— Administration (NN43001-611) for all tones that can be tested.

Exit LD 34 from the maintenance telephone:

****

—End—

Table 12
TDS tone tests

Input command

Dial pad
equivalent

Description

BSY#loop##

279#loop##

Provides busy tone from TDS loop specified.

C##

2##

Removes any active tone.

DIA#loop##

342#loop##

Provides dial tone from TDS loop specified.

OVF#loop##

683#loop##

Provides overflow tone from TDS loop specified.

RBK#loop##

725#loop##

Provides ringback tone from TDS loop specified.

RNG#loop##

764#loop##

Provides ring tone from TDS loop specified.

****

Exits TDS test program.

Nortel Communication Server 1000

Circuit Card Reference

NN43001-311

01.04

Standard

Release 5.0

23 May 2008
