Option settings
A set of four DIP switches provides selection among three values for
receiver impedance. Use SW8 for Trunk 0; use SW14 for Trunk 1 (see
17 "Trunk interface impedance switch settings" (page 86)
).
Table 17
Trunk interface impedance switch settings
Description
SW8/SW14 Switch Settings
75
off
off
on
off
100
on
off
off
on
120
off
off
off
on
Ring ground switches
A set of four DIP switches selects which Ring lines are connected to ground
(see
Table 18 "Ring ground switch settings" (page 86)
).
Table 18
Ring ground switch settings
Switch
Description
S2 switch setting
1
Trunk 0 Transmit
off - Ring line is not grounded
on- Ring line is grounded
2
Trunk 0 Receive
off - Ring line is not grounded
on - Ring line is grounded
3
Trunk 1 Transmit
off - Ring line is not grounded
on - Ring line is grounded
4
Trunk 1 Receive
off - Ring line is not grounded
on - Ring line is grounded
DCH mode and address select switches
One switch selects an on-board NTBK51AA D-Channel daughterboard
and an external MSDL/DCHI card. Four other switches provide the
daughterboard address (see
Table 19 "DCH mode and address select
).
