564 NT8D09 Analog Message Waiting Line card
Software service changes
Individual line interface units on the NT8D09 Analog Message Waiting
Line Card are configured using the Analog (500/2500-type) Telephone
Administration program LD 10.
The message waiting feature is enabled by entering data into the
customer data block using LD 15. See Software Input/Output Reference
— Administration (NN43001-611) for LD 10 and LD 15 service change
instructions.
Analog message waiting line cards with a vintage later than NT8D09AK
provide a fixed +2 dB transmission profile change in the gain of the D/A
convertor. See
Table 228 "Transmission Profile Changes" (page 564) .
This transmission profile change is used for control of end-to-end connection
loss. Control of such loss is a major element in controlling transmission
parameters such as received volume, echo, noise, and crosstalk. The loss
plan for the analog message waiting line card determines port-to-port loss
between an analog line card unit (port) and other Meridian 1 IPE ports.
LD 97 is used to configure the Meridian system for port-to-port loss. See
Software Input/Output Reference — Administration (NN43001-611) for LD
97 service change instructions.
Table 228
Transmission Profile Changes
Vintage A/D convertor gain D/A convertor gain
Previous to AK –3.5 dB –2.5 dB
AK and later –3.5 dB –0.5 dB
