Physical description 1057
LED State Definition
Off No red alarm.
YEL On (Yellow) A yellow alarm state has been detected.
Off No yellow alarm.
LBK On (Green) NTRB21 is in loop-back mode.
Off NTRB21 is not in loop-back mode.
Figure 301 "NTRB21 TMDI card faceplate" (page 1058) shows the faceplate
of the NTRB21 TMDI card.
The NTRB21 card uses a standard IPE-sized (9.5" by 12.5"), multi-layer
printed circuit board with buried power and ground layers. It is keyed to
prevent insertion in slot 10. The clock controller daughterboard is fastened
by standoffs and connectors.
