61
CHAPTER 3 CPU
●
Oscillation stabilization wait time at a reset
Option settings specify oscillation stabilization wait time at a reset (initial values of WT1 and WT0).
Cancellation of stop mode by external reset also applies oscillation stabilization wait time.
Table 3.6-3 shows the relationship between the active mode operation start conditions and oscillation
stabilization wait time.
Table 3.6-3 Active Mode Operation Start Conditions and Oscillation Stabilization Wait Time
Active mode operation start
condition
When power is turned
on
Cancellation of stop mode
External reset External interrupt
Selection of oscillation stabilization wait
time
Option settings SYCC: WT1, WT0
