CHAPTER 8 8/16-BIT CAPTURE TIMER/COUNTER
●
16-bit mode
To operate timer 0 as the counter function in the 16 bit mode, the function must be set as shown in Figure
8.7-3 .
Figure 8.7-3 Setting of Counter Function in 16-bit Mode
Counter function operation in the 16-bit mode is the same as interval timer function operation in the 16-bit
mode, except that the external clock is used instead of the internal clock.
Figure 8.7-4 shows counter function operation in 16-bit mode.
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
DDR3
0
TCCR CPIF CFCLR CPIEN CCMSK TCMSK EDGS1 EDGS0 RESV
TCR1 TIF1 TFCR1 T1IEN TCS12 TCS11 TCS10 TSTR1
TCR0 TIF0 TFCR0 T0IEN CINV TCS02 TCS01 TCS00 TSTR0
1 1 1
TCR2 PEN TSEL
TDR1
TDR0
TCPH
TCPL
: Used bit
: Unused bit
0 : Set "0"
1 : Set "1"
1 1 1
Setting of 00
Setting of the higher 8 bits of the counter value to be compared
Setting of the lower 8 bits of the counter value to be compared
Higher 8 bits of the number of detected events
Lower 8 bits of the number of detected events
