CHAPTER 7 8-BIT PWM TIMER

7.4.1

PWM Control Register (CNTR)

The PWM control register (CNTR) is used to select the operation mode (interval timer
operation or PWM timer operation) of the 8-bit PWM timer, switch the resolution of the
PWM timer functions, and select the count clock.

PWM Control Register (CNTR)

Figure 7.4-2 PWM Control Register (CNTR)

TIE

0

1

OE

0

1

TIR

0

1

TPE

0

1

P1

P0

0

0

1 t

INST

0

1

16 t

INST

1

0

64 t

INST

1

1

P/TX

0

1

t

INST

: Instruction cycle

bit7

bit6

bit5

bit4

bit3

bit2

bit1

bit0

0022

H

P/TX

P1

P0

TPE

TIR

OE

TIE

0-000000

B

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

Address

Initial value

Bit to enable an interrupt request

Disables interrupt request output.

Enables interrupt request output.

Bit to control the output pin

Used as the general-purpose port (P50)

Used as the output pin for the interval timer or PWM timer (PWM)

Interrupt request flag bit

Read

Write

The interval timer used

The PWM

timer used

The counter value does not

match the settings.

Not changed

Clears this bit.

The counter value matches

the settings.

Not changed. Does

not affect other settings.

Bit to enable the counter operation

Stops the counter operation.

Starts the counter operation.

Bits to select a clock

Internal

count

clock

Outputs an 8/16-bit capture timer/counter.

Bit to select the operation mode

Operates as the interval timer.

Operates as the PWM timer.

: Readable/Writable
: Initial value
