FUJITSU F2MC-8L F202RA - Manual (Page 393)

377
0018
H
BZCR Buzzer register R/W -----000
0019
H
TCCR Capture control register R/W 00000000
001A
H
TCR1 Timer 1 control register R/W 000-0000
001B
H
TCR0 Timer 0 control register R/W 00000000
001C
H
TDR1 Timer 1 data register R/W XXXXXXXX
001D
H
TDR0 Timer 0 data register R/W XXXXXXXX
001E
H
TCPH Capture data register H R XXXXXXXX
001F
H
TCPL Capture data register L R XXXXXXXX
0020
H
TCR2 Timer output control register R/W ------00
0021
H
Vacancy
0022
H
CNTR PWM control register R/W 0-000000
0023
H
COMR PWM compare register W XXXXXXXX
0024
H
EIC1 External interrupt 1 control register 1 R/W 00000000
0025
H
EIC2 External interrupt 1 control register 2 R/W ----0000
0026
H
Vacancy
0027
H
0028
H
SMC Serial mode control register R/W 00000-00
0029
H
SRC Serial rate control register R/W --011000
002A
H
SSD Serial status and data register R/W 00100-1X
002B
H
SIDR Serial input data register R XXXXXXXX
SODR Serial output data register W XXXXXXXX
002C
H
UPC Clock divided cycle selection register R/W ----0010
002D
H
to
002F
H
Vacancy
0030
H
ADC1 A/D control register 1 R/W -0000000
0031
H
ADC2 A/D control register 2 R/W -0000001
0032
H
ADDH A/D data register H R ------XX
0033
H
ADDL A/D data register L R XXXXXXXX
Table A-1 I/O Map (2 / 4)
Address
Register
abbreviation
Register name Read/write Initial value
