FUJITSU F2MC-8L F202RA - Manual (Page 41)

25
CHAPTER 3 CPU
IRQB FFE4
H
FFE5
H
IRQA FFE6
H
FFE7
H
IRQ9 FFE8
H
FFE9
H
IRQ8 FFEA
H
FFEB
H
IRQ7 FFEC
H
FFED
H
IRQ6 FFEE
H
FFEF
H
IRQ5 FFF0
H
FFF1
H
IRQ4 FFF2
H
FFF3
H
IRQ3 FFF4
H
FFF5
H
IRQ2 FFF6
H
FFF7
H
IRQ1 FFF8
H
FFF9
H
IRQ0 FFFA
H
FFFB
H
Mode data - * FFFD
H
Reset vector FFFE
H
FFFF
H
*: For MB89202 / MB89V201, FFFC
H
is prohibited. (Use "FF
H
".)
For MB89F202/F202RA, write "01
H
" to FFFC
H
to activate read protection,
otherwise write "FF
H
".
Table 3.1-1 Vector Table (2/2)
Vector call instruction
Address in the vector table
Upper digits Lower digits
