CHAPTER 1 OVERVIEW
D CMOS output
CMOS input
Hysteresis input (Resource input)
Pull-up resistor optional
E CMOS output
CMOS input
Pull-up resistor optional
P70 to P72 are large current drive type
F CMOS output
CMOS input
Analog input
N-ch open-drain output available
P40 to P43 are large current drive type
G CMOS output
CMOS input
Hysteresis input (Resource input)
Analog input
H CMOS input
Table 1.8-1 I/O Circuit Types (2/2)
Types Circuit Remarks
P-ch
N-ch
P-ch
Input enable
Input enable
Port
Resource
P-ch
N-ch
P-ch
Input enable
Port
P-ch
Open-drain control
Analog input
A/D enable
N-ch
Input enable Port
P-ch
Analog input
A/D enable
N-ch
P-ch
Input enable
Input enable
Port
Resource
Input enable
Port
