112
CHAPTER 4 I/O PORTS
Table 4.7-4 summarizes the operating modes of the pins of port 7.
Note:
When the pull-up resistor is selected by using the pull-up setting register, the pin state will be "H" level
instead of Hi-Z in stop mode (SPL = 1). During a reset, however, the pull-up is invalid with the pin
remaining at Hi-Z.
Table 4.7-4 Operating Modes of Pins of Port 7
Pin name Normal operation, sleep, stop (SPL = 0) Stop (SPL = 1) At a reset
P70 to P72 General-purpose I/O port Hi-Z Hi-Z
