CHAPTER 1 OVERVIEW

Note:

The oscillation is 12.5 MHz unless another condition such as the main clock maximum speed, the clock

cycle value, or conversion time is stated.

Table 1.2-2 CPU and Peripheral Functions of MB89202/F202RA Series

Item

Specification

CPU function

Number of basic instructions:

136 instructions

Instruction bit length:

8 bits

Instruction length:

1 to 3 bytes

Data bit length:

1, 8, or 16 bits

Minimum instruction execution time:

0.32 to 5.1

µs (at 12.5 MHz)

Interrupt processing time:

2.88 to 46.1

µs (at 12.5 MHz)

Periphera
l function

Port

General-purpose I/O port:

26 pins (Also serve as peripherals. 4 of which can be used as N-ch
open-drain I/O ports.)

21-bit
time-base
timer

21 bits
Interrupt cycle: 0.66 ms, 2.64 ms, 21 ms, or 335.5 ms with 12.5MHz main clock

Watchdog
timer

Reset occurrence cycle: When the main clock is at 12.5 MHz (minimum 335.5 ms)

8-bit
PWM
timer

8-bit interval timer operation (Square wave output is supported. Operating clock cycle:

1 t

INST

, 16 t

INST

, 64 t

INST

, and 8/16-bit capture timer/counter output)

8-bit resolution PWM operation (Conversion cycle:

256 t

INST

, 4096 t

INST

, 16384 t

INST

and 256 times 8/16-bit capture timer/counter output)

8/16-bit
capture
timer/
counter

8-bit capture timer/counter

× 1 channel + 8-bit timer or 16-bit capture timer/counter × 1 channel

When timer 0 or a 16-bit counter is operating, event-counting operation by external clock input
and square wave output are supported.

UART

Transfer data length: 6, 7, or 8 bits

8-bit serial
I/O

8 bits length, LSB first/MSB first selectability
One clock selectable from four operation clocks
(one external shift clock, three internal shift clocks: 2 t

INST

, 8 t

INST

, 32 t

INST

)

12-bit
PPG timer

Output frequency: Pulse width and cycle are selectable.

External
interrupt 1
(wake-up)

3 channels (interrupt vector, request flag, and request output enable)
Edge selectability (selectable from rising edge, falling edge, and both-edge modes)
Also available for wake-up from stop or sleep (Edge detection is also available in stop mode.)

External
interrupt 2
(wake-up)

8 inputs 1 channel (L level interrupt and input enable are independent.)
Also available for wake-up from stop or sleep (Level detection is also available in stop mode.)

10-bit A/D
converter

10-bit resolution

× 8 channels

A/D conversion function (Conversion time: 38 t

INST

)

Continuous activation by 8/16-bit capture timer/counter output or time-base timer output.

Wild
register

8-bit

Ч 2
