296
CHAPTER 13 UART
■ Receiving Status
Figure 13.4-5 shows the states (receiving status) of serial input data obtained from the received data flag bit
(RDRF) and error flag bit (ORFE).
Figure 13.4-5 Receiving Status
RDRF ORFE
0 0
0 1
1 0
1 1
: Initial value
Received data flag bit/Overrun/Framing error flag bit
No data
Framing error
Normal data
Overrun error (previous data remaining)
