CHAPTER 4 I/O PORTS
4.4.1 Registers of Port 4 (PDR4)
This section describes the registers associated with port 4.
■ Functions of Port 4 Registers
●
Port 4 data register (PDR4)
The PDR4 register indicates the state of the pins. For a pin set to function as an output port, the same value
("0"or "1") as held by the output latch can be read from this register. If the pin is set to function as an input
port, however, its output latch value cannot be read from the register.
Note:
When a bit manipulation instruction (SETB, CLRB) is executed, the output latch values, not the value
states of the pins, are read; thus, output latch values, excepting those for bits to be manipulated, do not
change.
Table 4.4-3 lists the functions of the port 4 registers.
Table 4.4-3 Functions of Port 4 Registers
Register
name
Data When being read When being written
Read/
Write
Address
Initial
value
Port 4
data
register
(PDR4)
0 Pin state is "L" level.
Output latch of "0" is set and
"L" level is output to the pin
in output port mode.
R/W 000F
H
----XXXX
B
1
Pin state
is "H"
level.
N-ch open-
drain type
Output latch of "1" is set and
the pin in output port mode
is set at Hi-Z.
CMOS
push-pull
type Output latch of "1" is set and
"H" level is output to the pin
in output port mode.
Port 4
data
direction
register
(DDR4) 0 Input port pin
The pin is set to function as
input pin with output
transistor operation disabled.
R/W 0010
H
----0000
B
1 Output port pin
The pin is set to function as
output pin with output
transistor operation enabled.
Port 4
output
format
setting
register
(OUT4)
0 N-ch open-drain type
Output format of the pin is
set to N-ch open-drain type.
R/W 0011
H
----0000
B
1 CMOS push-pull type
Output format of the pin is
set to CMOS push-pull type.
R/W : Readable and Writable
X
: Undefined
