5.5 Alarm Detection
u Alarm Codes, Causes, and Possible Solutions
Alarms are drive protection functions that do not necessarily cause the drive to stop. Once the cause of an alarm is removed,
the drive will return to the same status is was before the alarm occurred.
When an alarm has been triggered, the ALM light on the HOA keypad display blinks and the alarm code display flashes. If a
multi-function output is set for an alarm (H2-oo = 10), that output terminal will be triggered.
Note: If a multi-function output is set to close when an alarm occurs (H2-oo = 10), it will also close when maintenance periods are reached,
triggering alarms LT-1 through LT-3 (triggered only if H2-oo = 2F).
Table 5.11 Alarm Codes, Causes, and Possible Solutions
HOA Keypad Display Minor Fault Name
AEr
Station Address Setting Error (CC-Link, CANopen, MECHATROLINK)
Option card node address is outside of the acceptable setting range.
Cause Possible Solutions
Station number is set outside the possible setting
range.
• Set parameter F6-10 to the proper value when using a CC-Link option.
• Set parameter F6-35 to the proper value when using a CANopen option.
HOA Keypad Display Minor Fault Name
AUv
Power Supply Undervoltage
The input power supply voltage became equal to or lower than the Input Power Supply Undervoltage
Detection Level (L2-21).
200 V Class: Approximately 150 Vrms
400 V Class: Approximately 300 Vrms
HOA Keypad Display Minor Fault Name
bb
Baseblock
Drive output interrupted as indicated by an external baseblock signal.
Cause Possible Solutions
External baseblock signal was entered via one of
the multi-function input terminals (S1 to S8)
Check external sequence and baseblock signal input timing.
HOA Keypad Display Minor Fault Name
bUS
Option Communication Error
• The connection was lost after initial communication was established.
• Assign a Run command frequency reference to the option.
Cause Possible Solutions
Connection is broken or master controller stopped
communicating
• Check for faulty wiring.
• Correct the wiring.
• Check for disconnected cables and short circuits. Repair as needed.
Option is damaged If there are no problems with the wiring and the fault continues to occur, replace the option.
The option is not properly connected to the drive
• The connector pins on the option are not properly lined up with the connector pins on the drive.
• Reinstall the option.
A data error occurred due to noise
• Check options available to minimize the effects of noise.
• Take steps to counteract noise in the control circuit wiring, main circuit lines and ground wiring.
• Try to reduce noise on the controller side.
• Use surge absorbers on magnetic contactors or other equipment causing the disturbance.
• Use recommended cables or some other type of shielded line. Ground the shield to the controller
side or on the input power side.
• Separate the wiring for communication devices from the drive input power lines.
HOA Keypad Display Minor Fault Name
CALL
Serial Communication Transmission Error
Communication has not yet been established.
Cause Possible Solutions
