• To cancel Auto-Tuning, press the OFF key on the HOA keypad.
• When using a motor contactor, make sure it is closed throughout the Auto-Tuning process.
Table 4.23 Auto-Tuning Input Data
Motor Type Auto-Tuning Type Digital Input Digital Output
Induction
Motor
Stationary Auto-Tuning for Line-to-Line Resistance
Digital input functions
are disabled.
Maintains the status at the start of Auto-Tuning
Rotational Auto-Tuning for V/f Control Functions the same as during normal operation.
PM Motor
PM Motor Parameter Settings Digital output functions are disabled.
PM Stationary Auto-Tuning
Maintains the status at the start of Auto-Tuning.
PM Stationary Auto-Tuning for Stator Resistance
PM Rotational Auto-Tuning
Functions the same as during normal operation.
n Notes on Rotational Auto-Tuning
• Decouple the load from the motor to achieve optimal performance from Rotational Auto-Tuning. Rotational Auto-Tuning
is best suited for applications requiring high performance over a wide speed range.
• If it is not possible to decouple the motor and load, reduce the load so it is less than 30% of the rated load. Performing
Rotational Auto-Tuning with a higher load will set motor parameters incorrectly, and can cause irregular motor rotation.
• Ensure the motor-mounted brake is fully released, if installed.
• Connected machinery should be allowed to rotate the motor.
n Notes on Stationary Auto-Tuning
Stationary Auto-Tuning modes analyze motor characteristics by injecting current into the motor for approximately one minute.
WARNING! Electrical Shock Hazard. When executing stationary Auto-Tuning, voltage is applied to the motor before the motor rotates. Do
not touch the motor until Auto-Tuning is completed. Failure to comply may result in injury or death from electrical shock.
WARNING! Sudden Movement Hazard. If installed, do not release the mechanical brake during Stationary Auto-Tuning. Inadvertent brake
release may cause damage to equipment or injury to personnel. Ensure that the mechanical brake release circuit is not controlled by the
drive multi-function digital outputs.
Stationary Auto-Tuning for Line-to-Line Resistance
• Perform when entering motor data manually while using motor cables longer than 50 m.
• If the motor cables have been replaced with cables more than 50 m long after Auto-Tuning has already been performed, use
Stationary Auto-Tuning for line-to-line resistance.
u Auto-Tuning Interruption and Fault Codes
If tuning results are abnormal or the OFF key is pressed before completion, Auto-Tuning will be interrupted and a fault code
will appear on the HOA keypad.
B
LO
RE ESC
RUN STOP
ENTER RESET
DIGITAL OPERATOR JVOP-180
A
LO
RE ESC
RUN STOP
ENTER RESET
DIGITAL OPERATOR JVOP-180 ALM ALM
- A.TUNE -
X.XX Hz/ X.XXA
DRV
Tune Proceeding
Rdy
FWD
< << <<< >>> >> >
- MODE -
Er-03
STOP key
DRV
FWD RESET
A – During Auto-Tuning B – Auto-Tuning Aborted
Figure 4.29 Auto-Tuning Aborted Display
u Auto-Tuning Operation Example
The following example demonstrates Rotational Auto-Tuning for V/f.
