Kayenne XL Package — User Manual 23
Introduction
HD 1-M/E or 1.5-M/E system if it does not also have an I/O Expander
module. The 8RU chassis holds up to four M/E modules and/or I/O
Expander modules. One or two upgrade options can be added to a
Kayak HD or SD 2-M/E system, less any I/O Expander modules in the
chassis.
• Upgrade Kit for minor modifications of XtenDD panels to enable
control of a Kayak HD/SD video processor frame.
RamRecorder
The HD RamRecorder is a solid state video server with six input/output
channels. All stills and clips are stored within a common data pool and may
be accessed by all six output channels. The HD RamRecorder supports
video standards: 525, 625, 720, and 1080i.
Note To use the RamRecorder, a new 6910000xx or 7710060xx Controller Board
in the Mainframe is required. The new 6910000xx or 7710060xx Controller
Board does not support software earlier than 6.8.8.
Total HD RamRecorder storage size is based on line rate units and the
installed memory size of 4 GB or 8 GB, as shown in the following table.
Table 1. HD RamRecorder Storage Sizes
4GB 8GB
Line Rate Units Frames Seconds Frames Seconds
525i59.9 4911 163 9822 326
625i50 4161 165 8336 332
1080i50/sf25 863 33 1726 68
1080i60/59.9/sf30/29.9 863 28 1726 57
1080sf24/23.9 863 35 1726 71
720p50 1941 38 3883 77
720p60/59.9 1941 32 3883 64
