Functional Description
Table 3–36 shows the sequence of events for a 64-bit single-cycle memory
write target transaction. The 64-bit extension signals are not applicable to
the pci_mt32 and pci_t32 MegaCore functions.
Table 3–36. Single-Cycle Memory Write Target Transactions (Part 1 of 2)
Clock
Cycle
Event
1
The PCI bus is idle.
2
The address phase occurs.
3
The PCI MegaCore function latches the address and command, and decodes the address to check
if it falls within the range of one of its BARs. During clock cycle 3, the master deasserts the
framen
and req64n signals and asserts irdyn to indicate that only one data phase remains in the
transaction. For a single-cycle memory write target transaction, this phase is the only data phase in
the transaction. The MegaCore function uses clock cycle 3 to decode the address, and if the address
falls in the range of one of its BARs, the transaction is claimed.
4 If the PCI MegaCore function detects an address hit in clock cycle 3, several events occur during
clock cycle 4:
● The PCI MegaCore function informs the local-side device that it is going to claim the write
transaction by asserting
lt_framen and the bit on lt_tsr[5..0] that corresponds to the
BAR range hit. In Figure 3–15 , lt_tsr[0] is asserted indicating that a base address register
zero hit.
● The PCI MegaCore function drives the transaction command on l_cmdo[3..0] and address
on l_adro[31..0] .
● The PCI MegaCore function turns on the drivers of devseln , ack64n , trdyn , and stopn
getting ready to assert devseln and ack64n in clock cycle 5.
● lt_tsr[7] is asserted to indicate that the pending transaction is 64 bits.
● lt_tsr[8] is asserted to indicate that the PCI side of the PCI MegaCore function is busy.
5
The PCI MegaCore function asserts devseln to claim the transaction. Figure 3–15 also shows the
local side asserting lt_rdyn , indicating that it is ready to receive data from the PCI MegaCore
function in clock cycle 6.
To allow the local side ample time to issue a retry for the write cycle, the PCI MegaCore function does
not assert
trdyn in the first data phase unless the local side asserts lt_rdyn . If lt_rdyn is not
asserted in clock cycle 5 ( Figure 3–15 ), the PCI MegaCore function delays the assertion of trdyn .
6
The PCI MegaCore function asserts trdyn to inform the PCI master that it is ready to accept data.
Because irdyn is already asserted, this clock cycle is the first and last data phase in this cycle.
