Rockwell Automation DAG6.5.8 APPLICATION GUIDE SCADA SYSTEM User Manual
Page 57
Publication AG-UM008C-EN-P - February 2005
Configuring Enhanced PLC-5 Processors 2-19
Undelivered Messages
word 3
The number of messages that were sent by the processor but not
acknowledged by the destination device
Duplicate Messages
Received
word 9
The number of times the processor received a message packet identical
to the previous message packet
Bad Packet/No ACK
word 7
The number of incorrect data packets received by the processor for
which a no ACK was returned
DTR (Data Terminal Ready)
word 0;bit 4
The status of the DTR handshaking line (asserted by the processor)
DSR (Data Set Ready)
word 0;bit 2
The status of the DSR handshaking line (received by the processor)
RTS (Request to Send)
word 0;bit 1
The status of the RTS handshaking line (asserted by the processor)
CTS (Clear to Send)
word 0;bit 0
The status of the CTS handshaking line (received by the processor)
DCD (Carrier Detect)
word 0;bit 3
The status of the DCD handshaking line (received by the processor)
Status Field
Diagnostic File Location
Definition
