Rockwell Automation DAG6.5.8 APPLICATION GUIDE SCADA SYSTEM - Manual (Page 139)

1 Publication AG-UM008C-EN-P - February 2005
Chapter
4
Configuring SLC 5/03, 5/04, and 5/05
Processors
Chapter Objectives This chapter helps you set up an SLC 5/03, 5/04, or 5/05 processor as
a master station, as a slave station, as a radio modem station, or as a
station on a point-to-point link.
For information about See page
an overview of the tasks required to configure an SLC 5/03, 5/04, or
5/05 processor 4-2
installing the processor 4-2
using modems that support DF1 communication protocols 4-3
modem control line operation 4-5
configuring DF1 half-duplex channel 0 parameters 4-8
configuring the processor as a DF1 half-duplex master station using
standard communication 4-10
configuring the processor as a DF1 half-duplex master station using
message-based communication 4-18
configuring the processor as a slave station 4-22
configuring channel 0 poll timeout 4-25
configuring the processor as a radio modem station 4-27
configuring the processor for point-to-point communication 4-33
the types of messages you can send from an SLC 5/03, 5/04, or 5/05
processor to another processor; how to configure the MSG
instruction and some configuration characteristics 4-37
example MSG control blocks 4-43
