Apple Soundtrack Pro 2 User Manual
Page 269
Chapter 8
Basic Mixing in Soundtrack Pro
269
Signal Routing for a Separate Music and Effects Mix in Surround
When you shift from a stereo project to surround, you need to keep in mind some
minor signal routing consequences. This section discusses what changes you would
make to the submix and output settings. (For information about creating a surround
version of a stereo project, see “
Converting a Stereo Mix to 5.1 Surround
First, assuming that the music and effects are mixed over six surround channels, those
submixes must be routed to the Surround 1-6 output. The Dialogue submix could
either remain routed to the Stereo 1,2 output jacks to be added to the Surround 1-6
mix or routed to the center channel at the submix, or could be panned to the center
channel in a surround signal, as shown below.
To create the surround version of the separate music and effects mix (as described
earlier), you route the Dialogue submix to any output channels other than 1-6. This
example uses channels 7 and 8, the last two available output channels, thus isolating
the dialogue from the music and effects.
1
2
3
4
Tracks
5
6
7
8
Right
Left
Center
Right
surround
Left
surround
LFE
Submix bus
Channels 1– 6
Hardware
outputs
Master
bus
4
3
2
1
6
7
8
5
Channels 1– 6
Music
Channels 1–6
Effects
Master
bus
4
3
2
1
6
7
8
5
Music
Effects
Audio clip
Surround panner
Dialogue
1
2
3
4
Tracks
Submix bus
Channels 7, 8
Dialogue
5
6
7
8
Output
device
Hardware
outputs
Master
bus
4
3
2
1
6
7
8
5
Stereo panner
Audio clip
Surround panner
Channels 1– 6
Music
Channels 1–6
Effects
