70
K-Config - Assigning the Peripheral Devices to Master and Auxiliary Device Ports
The Ethernet port settings are complete:
7.3.1
Setting the Volume Properties
For Master controllers with an integrated power amplifier (for example, the SV-551 and SV-552) you can set the
volume properties via the Port Manager (analog or digital), as illustrated in
Figure 116: Set Volume Properties
Set the volume control to:
Analog, if the volume of the integrated amplifier is controlled by an external analog audio knob (via the
SV-551/SV-552 10k volume level input port, connected either to an analog audio knob of a K-NET Aux device
such as the RC-63AL, or any other compatible volume level knob)
Digital, if the volume of the integrated power audio amplifier is controlled by an auxiliary device with a digital knob
(for example, RC-63DL). In this example, the amplifier
port should be “assigned” via the Port Manager to the
relevant RC-63DL to achieve volume control.
For digital audio level control, select the auxiliary device that will control the audio
7.3.2
Uploading EDID Information
You can upload EDID information (created with the Kramer EDID Designer application, for compatible devices) via the
Port Manager tab. For example, to load the EDID for the WP-501, click the Driver field:
Figure 117: Selecting the EDID File
Select the EDID file to upload and click Open:
