60 K-Config - Defining the Control Room via the Project Navigator
For example, you can change the appearance of the virtual front panel as illustrated in Figure 95 :
Figure 95: Custom Virtual Device Appearance in K-Config
To change the appearance of the virtual device front panel, as illustrated in Figure 95 , do the following (you do not
have to follow the subsequent steps in the same order):
1. In the Virtual Device Properties window, delete buttons 4, 5 and 6, frame 1 and frame 2, and Label 2, as
illustrated in Figure 96 :
Figure 96: Editing the Virtual Device Appearance (Step 1)
2. Set the size of the front panel, the size of the buttons (up to 32 buttons can be added), the label size and their
position, as well as the Device Name (see Figure 97 ):
Figure 97: Editing the Virtual Device Appearance (Step 2)
