K-Config – Adding Actions to a Trigger 107
Figure 193: Panels Status – Button Color and Behavior Selected
4. In the top drop-down box, select the disable or enable the button.
For example, you can disable the source selection button when the projector is OFF; this command will
prevent source switching while the projector is OFF.
5. In the lower drop-down box , if the button’s behavior was set to states, you can define the button status for
each state.
6. Click the Add to list button.
9.4.2 The LCD Label
LCD Label lets you alter an LCD label on the front panel of the device. To do so:
1. Select the LCD Label (its frame turns blue).
2. From the drop-down list select No Change, Text, Date / Time or Blank:
 No Change: the current
status will not change
 Text: type a label text
 Date/Time: select the date
format, DD/MM/YY or
MM/DD/YY and the time
format, 12H or 24H
 Blank: turns the label blank
