22
K-Config - Getting to Know K-Config
4.3.3
The Windows Menu
The Windows menu lists layout operations and all the available windows. Some of the windows (checked in the
Windows menu) appear in the default layout. At any time you can add or delete a window from the main window layout
and by clicking Default Layout you can return to the default layout.
Figure 38: The Window Menu
Menu Command
Function
Save Layout
Saves the current windows layout
Load Layout
Load a saved layout
Default Layout
Set to the default layout
Save Layout on Exit
Set to On to save
Default
layout
windows
Project Navigator Set the controlled room devices
Triggers
Arrange the triggers
Action List
Lists the actions added to the trigger
Action Editor
Select the actions to add to the trigger
Device View
Displays the selected device front panel
Port Manager
Click to open the Port Manager window
Device Settings
Click to open the Device Settings window see
Section
Web Settings
Click to open the Web Settings window (see
Section
4.3.3.1 Web Settings
Web settings are used to set the Web page logo, room name and so on for Master room controllers that have an ETH
port for remote access from a browser (and by that are also Site-CTRL compatible).
Settings window:
Figure 39: Window Menu
– Web Settings Window
The logo file type can be either jpg, jpeg or png, up to 500 Kbytes in size.
For best i
mage quality, when viewed on the device’s Web pages, we recommend that you use images of H 200px and
W 790px pixels.
Kramer
Site-CTRL
is a powerful A/V assets management tool. It offers real-time monitoring and control of
Kramer Master controllers installed in an A/V site and the A/V equipment connected to them. The Kramer
Site-CTRL
downloadable version can monitor and control up to 100 Kramer Master controllers.
i
