Section 4. Setting up Datalogger Networks
Set Station Clock – Press this button to manually set the clock to that of the
LoggerNet server.
The Allowed Clock Deviation setting will prevent a manual clock
set from being carried out if the difference between the
datalogger’s and server’s clocks is less than the specified
deviation.
4.2.4.4.6 Program Tab
The program tab displays the name of the program currently running in the
datalogger, if it is known by the LoggerNet server. Table-based dataloggers
store program information in the table definitions. If the table definitions have
been retrieved from the datalogger, LoggerNet should know the name of the
running program. However, mixed-array dataloggers do not store the program
name internally. LoggerNet is made aware of the program name and output
table information when a new program is sent, or when a DLD file that
contains this information is associated with the datalogger. To send a new
program to the datalogger, press the Send button. To associate a program
name with the datalogger, press the Associate button. See Section 5.1.6,
Program Association, for more information.
4.2.4.4.7 File Retrieval Tab (CR1000, CR3000, CR800 Series, and Edlog Dataloggers with
PakBus Operating Systems)
Retrieval Mode – This option determines the schedule for file retrieval.
Disabled – No files are retrieved.
Follow Scheduled Data Collection – Files will be retrieved on the same
schedule that has been set up for scheduled data collection on the
Schedule tab. An attempt to retrieve the files will be made at the
scheduled time, only if scheduled collection is enabled. However,
regardless of whether or not scheduled collection is enabled, an attempt to
retrieve the files will take place when a manual poll is performed using a
Collect Now button, when a call-back occurs, or when a task calls the
station.
New Schedule – Files will be retrieved based on the Base Date and Time
and Collection Interval defined below. Only the new schedule will
trigger file retrieval. Attempts to retrieve files will be made following the
new schedule, whether or not scheduled collection is enabled.
Base Date/Time – Enter a date and a time that the first file retrieval attempt for
the device should occur. If the date and time reflected by these fields has
already passed, retrieval will be attempted immediately when the schedule is
enabled.
Retrieval Interval – Enter the interval on which files should be retrieved from
the device. The retrieval interval is relative to the Base Date and Time entries.
For instance, if the Base Time is set at 12:15 and the interval is set for 1 hour,
file retrieval will be attempted at 12:15, 1:15, 2:15, etc. The format for this
field is 00 d(ays) 00 h(ours) 00 m(inutes) 00 s(econds) 00 m(illi)s(econds).
NOTE
