Campbell Scientific LoggerNet Datalogger Support Software - Manual (Page 330)

Section 8. Working with Data Files on the PC
Goto Bookmark
If the data panel contains one or more bookmarks, hovering over the Goto
Bookmark menu item will bring up a list of the current bookmarks. Selecting
a bookmark from the list will automatically move the data panel to that record.
The shortcut Ctrl-n, where n is the number of the bookmark, can also be used
to move the data file to the desired bookmark.
Delete Bookmark
If the data panel contains one or more bookmarks, hovering over the Delete
Bookmark menu item will bring up a list of the current bookmarks. Selecting
a bookmark from the list will delete the bookmark.
Delete All Bookmarks
Deletes all bookmarks from the data panel.
View Record
Brings up the current record in a Record View window showing each column
heading and the data value. (The Record View window can be brought up
directly by clicking to the left of the record.)
8.1.8.2 Graphs
Right-clicking on a graph will bring up a menu from which you can choose
Export to save the graph in a choice of formats, Copy to Clipboard to place
the graph on the clipboard, Print to print the graph, or Options to bring up the
graph’s Options dialog box.
8.1.8.3 Traces
Right-clicking on a trace name in the list on the right side of a Line Graph,
Histogram, Rainflow Histogram, or FFT brings up a menu from which you can
choose Edit Selection to bring up the trace options dialog box, Delete
Selection to delete the selection from the graph, or Selection Summary to see
information about the trace, the data file, and the datalogger and program that
generated the data file. For a Line Graph, this list also includes Set as Left
Axis to use the selected trace’s scale on the left y-axis, Set as Right Axis to
use the selected trace’s scale on the right y-axis, Check All to check all traces
and make them visible on the graph, and Uncheck All to uncheck all traces and
remove them from the graph.
8.1.9 Printing Options
8.1.9.1 Print Setup
Select File | Print Setup from the View Pro toolbar to set print options such as
printer, paper size and source, orientation, duplex mode, pages per sheet, etc.
Note that many of these options can also be set from the dialog box that is
brought up when the Print button is pressed or from the Print Preview
screen.
8-32
