Appendix F. Calibration and Zeroing
F.2 Writing Calibration Programs with the CRBasic
Editor
F.2.1 The FieldCal Instruction
If you wish to make measurements that will be calibrated as discussed above,
you should use the FieldCal instruction within the CRBasic program. When
the program is running in the datalogger, you can use the LoggerNet
Calibration Wizard to perform the actual calibrations (in real-time) on the
sensors that were previously designated for calibration. You can also perform
a manual calibration against a running program using the LoggerNet Numeric
Display (see Appendix F.5, Using the Calibration Wizard with Running
Programs) or from a keyboard display connected directly to the datalogger.
The FieldCal instruction works together with other related CRBasic
instructions to complete the calibration task. These instructions are shown in
TABLE F-.
TABLE F-1. The FieldCal Instruction “Family”
Instruction Description
FieldCal This is the main calibration instruction. The CRBasic
program should contain one FieldCal instruction per
measurement requiring calibration. This instruction is
placed after the measurement instruction to which it
applies.
LoadFieldCal (optional) This instruction loads values into program
variables from the calibration file (*.cal), if it exists. It
will also indicate whether the attempt to load those
values was successful or not by returning a Boolean
(true/false) result.
SampleFieldCal (optional) This is a table output instruction. It writes the
latest calibration values for all calibrated measurements
to a data table (separate from the *.cal file).
NewFieldCal (optional) This is a Boolean system value indicating
when a calibration has succeeded. During one scan cycle
after a calibration has occurred this value will be true. Its
value is then set to false until another calibration occurs.
The value of this variable cannot be set within a CRBasic
Program, but only evaluated. The main purpose for this
variable is to be used together with the SampleFieldCal
instruction to output one table record per calibration to a
specified table.
To set up a measurement for calibration in CRBasic, first insert the
instruction(s) that make the measurement, using variables for the multiplier
and/or offset. Then add a FieldCal instruction after the measurement
instruction and refer back to the measurement being calibrated using the
variable containing the measured output. Provide the FieldCal instruction with
the variables holding the multiplier and the offset of the measured sensor. If
you need to retrieve a calibration value into multipliers and offsets upon
