Appendix C. Table-Based Dataloggers
TABLE C-1. Example of Status Table Entries (CR10T)
Battery Current value of the battery voltage. This measurement is made in the
background calibration.
PanelTemp Current Panel temperature measurement.
LithiumBattery A Boolean variable signaling “True” (–1) if the lithium battery is OK and
“False” (0) if not. The lithium battery is loaded and a comparator checked
every 4 seconds to verify that the battery is charged.
CPUSignature The Operating System signature. The value should match the value
obtained by running the CSI sig program on the name.obj operating system
file.
DLDSignature Signature of the current running program file.
ProgSignature Signature of the compiled binary data structure for the current program.
This value is independent of comments added or non functional changes to
the program file.
PC-CardBytesFree Gives the number of bytes free on the PC-Card.
MemoryFree Amount (in bytes) of unallocated memory on the CPU (SRAM). The user
may not be able to allocate all of free memory for data tables as final
storage must be contiguous. As memory is allocated and freed there may
be holes that are unusable for final storage, but that will show up as free
bytes.
DLDBytesFree Amount of free space in the CPU RAM disk that is used to store program
files.
ProcessTime Time in microseconds that it took to run through processing on the last
scan. Time is measured from the end of the EndScan instruction (after the
measurement event is set) to the beginning of the EndScan (before the wait
for the measurement event begins) for the subsequent scan.
MaxProcTime The maximum time required to run through processing for the current
scan. This value is reset when the scan exits.
MeasureTime The time required by the hardware to make the measurements in this scan.
The sum of all integration times and settling times. Processing will occur
concurrent with this time so the sum of measure time and process time is
not the time required in the scan instruction.
SkippedScan Number of skipped scans that have occurred while running the current
program.
SlowProcTime Time required to process the current slow scan. If the user has slow scans
then this variable becomes an array with a value for the system slow scan
and each of the user’s scans.
MaxSlowProcTime The maximum Time required to process the current slow scan. If the user
has slow scans then this variable becomes an array with a value for the
system slow scan and each of the user’s scans.
LastSlowScan The last time that this slow scan executed. If the user has slow scans then
this variable becomes an array with a value for the system slow scan and
each of the user’s scans.
