257
Example
# raidvchkscan -v jnl 0
JID MU CTG JNLS AP U(%) Q-Marker Q-CNT D-SZ(BLK) Seq# Nnm LDEV#
001 0 1 PJNN 4 21 43216fde 30 512345 62500 2 265
002 1 2 PJNF 4 95 3459fd43 52000 512345 62500 3 270
003 0 3 PJSN 4 0 - - 512345 62500 1 275
004 0 4 PJSF 4 45 1234f432 78 512345 62500 1 276
005 0 5 PJSE 0 0 - - 512345 62500 1 277
006 - - SMPL - - - - 512345 62500 1 278
007 0 6 SMPL 4 5 345678ef 66 512345 62500 1 278
JID displays the journal group ID.
MU displays the mirror descriptions on CA-Journal.
CTG displays the CT group ID.
JNLS displays the following status for the journal
group.
SMPL indicates that the journal volume doesn't
have a pair or the pair has been deleted.
P(S)JNN = “P-(S-)VOL Journal Normal Normal”
P(S)JSN = “P-(S-)VOL Journal Suspend Normal”
PJNF = “P-(S-)VOL Journal Normal Full”
P(S)JSF = “P-(S-)VOL Journal Suspend Full”
P(S)JSE = “P-(S-)VOL Journal Suspend Error,”
with link failure
AP (active path) displays the following two conditions,
according to the pair status.
In the case of pair status PJNL or SJNL (except
suspend state), this field shows the number of
active paths on the initiator port in CA-Journal
links. A “-” indicates “unknown.”
In case of pair status SJNL (suspend state), this field
shows the result of the suspend operation and
indicates whether or not all data on PJNL (P-VOL)
were passed (synchronized) to S-JNL (S-VOL)
