3
CATC BTT RAINER 2.20 C HAPTER 1
User’s Manual Overview
The following headsets have been successfully tested with BTTrainer:
• RadioShack® 43-1957 Super Lightweight Hands-Free Headset
• GN Netcom® GNX Mobile M200
• Motorola® Retractable Hands-Free Headset Model # 98196G
• Belkin® Universal 2.5 mm Personal Hands-Free Kit F8V920-PL
• Coby® CV-M20 Earphone with Built-In Microphone
• Plantronics® CHS122N Hands-Free Headset
• Plantronics M110 Headset for Cordless and Mobile Phones
1.5 Specifications
The following specifications describe a BTTrainer system.
1.5.1 Package
Connectors: Host connection (USB, type ‘B’)
Audio connection (2.5 millimeter audio stereo jack)
1.5.2 Environmental Conditions
Operating Range: 0 to 55 °C (32 to 131 °F)
Storage Range: -20 to 80 °C (-4 to 176 °F)
Humidity: 10 to 90%, non-condensing
1.5.3 Host Compatibility
Works with any PC equipped with a functioning USB port and a Microsoft Windows 98 SE,
Windows Me, Windows 2000, or Windows XP operating system.
1.5.4 Hardware Interfaces
• Standard USB Interface — connects to the host computer
• 2.4 GHz (ISM band) External Antenna.
• 2.5 mm audio stereo jack
1.6 Product Warranty
CATC offers a one-year limited warranty on its products.
