W90P710CD/W90P710CDG

Publication Release Date: September 19, 2006

- 93 -

Revision B2

REGISTER ADDRESS R/W

DESCRIPTION

RESET

VALUE

CAHCON

0xFFF0_2004

R/W Cache control register

0x0000_0000

RESERVED

DRWB ULKS ULKA LDLK FLHS FLHA DCAH ICAH

BITS

DESCRIPTION

[31:8] RESERVED

[7] DRWB

Drain write buffer
Forces write buffer data to be written to main memory.

[6] ULKS

Unlock I-Cache/D-Cache single line
Unlocks the I-Cache/D-Cache per line. Both WAY and ADDR bits in
CAHADR register must be specified.

[5] ULKA

Unlock I-Cache/D-Cache entirely
Unlocks the entire I-Cache/D-Cache, the lock bit “L” will be cleared
to 0.

[4] LDLK

Load and Lock I-Cache/D-Cache
Loads the instruction or data from external memory and locks into
cache. Both WAY and ADDR bits in CAHADR register must be
specified.

[3] FLHS

Flush I-Cache/D-Cache single line
Flushes the entire I-Cache/D-Cache per line. Both WAY and ADDR
bits in CAHADR register must be specified.

[2] FLHA

Flush I-Cache/D-Cache entirely
To flush the entire I-Cache/D-Cache, also flushes any locked-down
code. If the I-Cache/D-Cache contains locked down code, the
programmer must flush lines individually

[1] DCAH

D-Cache selected
When set to “1”, the command set is executed with D-Cache.

[0] ICAH

I-Cache selected
When set to “1”, the command set is executed with I-Cache.
