W90P710CD/W90P710CDG
- 546 -
Timer Control Registers Map
REGISTER ADDRESS R/W
DESCRIPTION
RESET
VALUE
TCR0
0xFFF8_1000 R/W
Timer Control Register 0
0x0000_0005
TCR1
0xFFF8_1004 R/W
Timer Control Register 1
0x0000_0005
TICR0
0xFFF8_1008 R/W
Timer Initial Control Register 0
0x0000_00FF
TICR1
0xFFF8_100C R/W
Timer Initial Control Register 1
0x0000_00FF
TDR0
0xFFF8_1010
R
Timer Data Register 0
0x0000_0000
TDR1
0xFFF8_1014
R
Timer Data Register 1
0x0000_0000
TISR
0xFFF8_1018 R/C
Timer Interrupt Status Register
0x0000_0000
WTCR
0xFFF8_101C R/W
Watchdog Timer Control Register
0x0000_0000
AIC Control Registers Map
REGISTER ADDRESS R/W
DESCRIPTION
RESET
VALUE
AIC_SCR1 0xFFF8_2004
R/W
Source Control Register 1
0x0000_0047
AIC_SCR2 0xFFF8_2008
R/W
Source Control Register 2
0x0000_0047
AIC_SCR3 0xFFF8_200C
R/W
Source Control Register 3
0x0000_0047
AIC_SCR4 0xFFF8_2010
R/W
Source Control Register 4
0x0000_0047
AIC_SCR5 0xFFF8_2014
R/W
Source Control Register 5
0x0000_0047
AIC_SCR6 0xFFF8_2018
R/W
Source Control Register 6
0x0000_0047
AIC_SCR7 0xFFF8_201C
R/W
Source Control Register 7
0x0000_0047
AIC_SCR8 0xFFF8_2020
R/W
Source Control Register 8
0x0000_0047
AIC_SCR9 0xFFF8_2024
R/W
Source Control Register 9
0x0000_0047
AIC_SCR10 0xFFF8_2028 R/W
Source Control Register 10
0x0000_0047
AIC_SCR11 0xFFF8_202C R/W
Source Control Register 11
0x0000_0047
AIC_SCR12 0xFFF8_2030 R/W
Source Control Register 12
0x0000_0047
AIC_SCR13 0xFFF8_2034 R/W
Source Control Register 13
0x0000_0047
AIC_SCR14 0xFFF8_2038 R/W
Source Control Register 14
0x0000_0047
AIC_SCR15 0xFFF8_203C R/W
Source Control Register 15
0x0000_0047
AIC_SCR16 0xFFF8_2040 R/W
Source Control Register 16
0x0000_0000
AIC_SCR17 0xFFF8_2044 R/W
Source Control Register 17
0x0000_0000
AIC_SCR18 0xFFF8_2048 R/W
Source Control Register 18
0x0000_0000
AIC_SCR19 0xFFF8_204C R/W Source Control Register 19
0x0000_0047
AIC_SCR20 0xFFF8_2050 R/W Source Control Register 20
0x0000_0047
