W90P710CD/W90P710CDG
- 540 -
USB Device Register Map, continued
REGISTER OFFSET R/W DESCRIPTION
RESET
VALUE
EPC_INFO 0xFFF0_6080 R/W USB endpoint C information register 0x0000_0000
EPC_CTL 0xFFF0_6084 R/W USB endpoint C control register 0x0000_0000
EPC_IE 0xFFF0_6 088 R/W USB endpoint C Interrupt Enable register 0x0000_0000
EPC_IC 0xFFF0_608C W USB endpoint C interrupt clear register 0x0000_0000
EPC_IS 0xFFF0_6090 R USB endpoint C interrupt status register 0x0000_0000
EPC_ADDR 0xFFF0_6094 R/W USB endpoint C address register 0x0000_0000
EPC_LENTH 0xFFF0_6098 R/W USB endpoint C transfer length register 0x0000_0000
EPA_XFER 0xFFF0_609C R/W USB endpoint A remain transfer length register 0x0000_0000
EPA_PKT 0xFFF0_60A0 R/W USB endpoint A remain packet length register 0x0000_0000
EPB_XFER 0xFFF0_60A4 R/W USB endpoint B remain transfer length register 0x0000_0000
EPB_PKT 0xFFF0_60A8 R/W USB endpoint B remain packet length register 0x0000_0000
EPC_XFER 0xFFF0_60AC R/W USB endpoint C remain transfer length register 0x0000_0000
EPC_PKT 0xFFF0_60B0 R/W USB endpoint C remain packet length register 0x0000_0000
SD Control Register Map
REGISTER OFFSET R/W DESCRIPTION RESET VALUE
SDGCR 0xFFF0_7000 R/W SD Global Control Register 0x0000_0000
SDDSA 0xFFF0_7004 R/W
SD DMA Transfer Starting Address
Register
0x0000_0000
SDBCR 0xFFF0_7008 R/W SD DMA Byte Count Register 0x0000_0000
SDGIER 0xFFF0_700C R/W SD Global Interrupt Enable Register 0x0000_0000
SDGISR 0xFFF0_7010 R/W SD Global Interrupt Status Register 0x0000_0000
SDBIST 0xFFF0_7014 R/W SD BIST Register 0x0000_0000
SDCR 0xFFF0_7300 R/W SD Control Register 0x0000_0000
SDHINI 0xFFF0_7304 R/W SD Host Initial Register 0x0000_0018
SDIER 0xFFF0_7308 R/W SD Interrupt Enable Register 0x0000_0000
SDISR 0xFFF0_730C R/W SD Interrupt Status Register 0x0000_00XX
SDAUG 0xFFF0_7310 R/W SD Command Argument Register 0x0000_0000
SDRSP0 0xFFF0_7314 R SD Receive Response Token Register 0 0xXXXX_XXXX
SDRSP1 0xFFF0_7318 R SD Receive Response Token Register 1 0x0000_XXXX
SDBLEN 0xFFF0_731C R/W SD Block Length Register 0x0000_0000
