W90P710CD/W90P710CDG
- 322 -
Continued
BITS DESCRIPTIONS
[7:6]
BCLK_SEL
[1:0]
IIS serial data clock frequency selection bit
BCLK_SEL[1:0]=00, 32fs is selected (fs is sampling rate), when
FS_SEL=0, the frequency of bit clock is MCLK/8, when
FS_SEL=1, the frequency of bit clock is MCLK/12.
BCLK_SEL[1:0]=01, 48fs is selected (only when FS_SEL=1, this
term could be selection), when FS_SEL=1, the frequency of bit
clock is MCLK/8.
The BCLK_SEL[1:0] bits are read/write
[5] FS_SEL
IIS sampling frequency selection bit
FS_SEL=0, FMCLK/256 is selected (FMCLK is the frequency of
signal MCLK)
FS_SEL=1, FMCLK/384 is selected
The FS_SEL bit is read/write
[4] MCLK_SEL
IIS MCLK output selection bit
MCLK_SEL=0, IIS MCLK output will follow the PRS[3:0] setting.
MCLK_SEL=1, IIS MCLK output will be the same with FPLL.
The MCLK_SEL bit is read/write
[3] FORMAT
IIS format selection bits
FORMAT=0, IIS compatible format is selected
FORMAT=1, MSB-justified format is selected
The FORMAT bit is read/write
[2:0] Reserved -
AC-link Control Register (ACTL_ACCON)
REGISTER ADDRESS R/W DESCRIPTION RESET VALUE
ACTL_ACCON 0xFFF0_902C R/W AC-link control register 0x0000_0000
The ACTL_ACCON register is the AC-link basic operation control register.
