W90P710CD/W90P710CDG
Publication Release Date: September 19, 2006
- 221 -
Revision B2
USB Endpoint B Interrupt Clear Register (EPB_IC)
REGISTER
ADDRESS
R/W
DESCRIPTION
RESET VALUE
EPB_IC
0xFFF06070
W
USB endpoint B interrupt clear register 0x0000_0000
31
30
29
28
27
26
25
24
Reserved
23
22
21
20
19
18
17
16
Reserved
15
14
13
12
11
10
9
8
Reserved
7
6
5
4
3
2
1
0
Reserved
EPB_CF_IC
EPB_BUS_ERR_IC
EPB_DMA_IC EPB_ALT_IC
EPB_TK_IC EPB_STL_IC
BITS
DESCRIPTIONS
[31:6]
Reserved
[5]
EPB_CF_IC
Endpoint B clear feature interrupt clear
[4]
EPB_BUS_ERR_IC
Endpoint B system bus error interrupt clear
[3]
EPB_DMA_IC
Endpoint B DMA transfer complete interrupt clear
[2]
EPB_ALT_IC
Endpoint B alternate setting interrupt clear
[1]
EPB_TK_IC
Endpoint B token input interrupt clear
[0]
EPB_STL_IC
Endpoint B stall interrupt clear
USB Endpoint B Interrupt Status Register (EPB_IS)
REGISTER
ADDRESS
R/W
DESCRIPTION
RESET VALUE
EPB_IS
0xFFF06074
R
USB endpoint B interrupt status register
0x0000_0000
