W90P710CD/W90P710CDG
Publication Release Date: September 19, 2006
- 275 - Revision B2
FIFO1 Real Column Count Register (F1REALCULCNT)
REGISTER ADDRESS R/W DESCRIPTION RESET VALUE
FIFO1REALCULCNT 0xFFF0_8048 R/W FIFO1 real column count 0x0000_0000
31 30 29 28 27 26 25 24
Reserved
23 22 21 20 19 18 17 16
Reserved
15 14 13 12 11 10 9 8
F1REALCOLCNT[15:8]
7 6 5 4 3 2 1 0
F1REALCOLCNT[7:0]
BITS DESCRIPTIONS
[31:16] Reserved Reserved
[15:0] F1REALCOLCNT These bits indicate the FIFO1 real column count per-frame of video
FIFO2 Real Column Count (F2REALCULCNT)
REGISTER ADDRESS R/W DESCRIPTION
RESET
VALUE
FIFO2REALCULCNT 0xFFF0_804C R/W FIFO2 real column count 0x0000_0000
31 30 29 28 27 26 25 24
Reserved
23 22 21 20 19 18 17 16
Reserved
15 14 13 12 11 10 9 8
F2REALCOLCNT[15:8]
7 6 5 4 3 2 1 0
F2REALCOLCNT[7:0]
