[2:1] WAITVT
Valid time of nWAIT signal
W90P710 recognizes the nWAIT signal at the next “nth” MCLK rising
edge after the nOE or nWBE active cycle. WAITVT bits determine the n.
WAITVT [2:1]
nth MCLK
0 0
1
0 1
2
1 0
3
1 1
4
[0]
LITTLE
Little Endian mode
After power on reset, the content of LITTLE is the Power-On Setting
value from D14 pin. If pin D14 is pull-down, the external memory format
is Big Endian mode. If pin D14 is pull-up, the external memory format is
Little Endian mode. For more detail, refer to Power-On Setting of System
Manager.
NOTE: This bit is read only.
ROM/Flash Control Register （ROMCON）
REGISTER ADDRESS R/W
DESCRIPTION
RESET
VALUE
ROMCON
0xFFF0_1004
R/W ROM/FLASH control register
0x0000_0XFC
31
30
29
28
27
26
25
24
BASADDR
23
22
21
20
19
18
17
16
BASADDR SIZE
15
14
13
12
11
10
9
8
RESERVED tPA
7
6
5
4
3
2
1
0
tACC
BTSIZE
PGMODE
