W90P710CD/W90P710CDG
- 440 -
6.17 Smart Card Host Interface
The Smart Card resides in APB bus.
The whole chip of W90P710 operates at voltage level of 3.3 V except Smart Card Interface port's I/O
pins that are at 5 V to be compatible with mainstream Smart Card implementations. Advanced power
management feature further optimizes power consumption whether in operation or in power down
mode.
y ISO-7816 compliant
y PC/SC T=0, T=1 compliant
y 16-byte transmitter FIFO and 16-byte receiver FIFO
y FIFO threshold interrupt to optimize system performance
y Programmable transmission clock frequency
y Versatile baud rate configuration
y UART-like register file structure
y Versatile 8-bit, 16-bit, 24-bit time-out counter for Answer-To-Reset (ATR) and waiting times
processing.
y Parity error counter in reception mode and in transmission mode with automatic re-transmission.
y Automatic activation and deactivation sequence through an independence sequencer
6.17.1 Register Mapping
R: read only, W: write only, R/W: both read and write, C: Only value 0 can be written.
Table 6.12.2.1 Smart Card Host Interface 0 Register Map
REGISTER ADDRESS R/W DESCRIPTION RESET VALUE
Smartcard Host Interface 0
SCHI_RBR0 0xFFF8_5000 (BDLAB=0) R Receiver Buffer Register Undefined
SCHI_TBR0 0xFFF8_5000 (BDLAB=0) W Transmitter Buffer Register Undefined
SCHI_IER0 0xFFF8_5004 (BDLAB=0) R/W Interrupt Enable Register 0x0000_0080
SCHI_ISR0 0xFFF8_5008 (BDLAB=0) R Interrupt Status Register 0X0000_00C1
SCHI_SCFR0 0xFFF8_5008 (BDLAB=0) W Smart card FIFO Control Register 0x0000_0000
SCHI_SCCR0 0xFFF8_500C R/W Smart card Control Register 0x0000_0018
SCHI_CBR0 0xFFF8_5010 R/W Clock Base Register 0x0000_000C
SCHI_SCSR0 0xFFF8_5014 R Smart Card Status Register 0x0000_0060
SCHI_GTR0 0xFFF8_5018 R/W Guard Rime Register 0x0000_0001
SCHI_ECR0 0xFFF8_501C R/W Extended Control Register 0x0000_0052
SCHI_TMR0 0xFFF8_5020 R/W Test Mode Register 0x0000_0000
SCHI_TOC0 0xFFF8_5028 R/W Time out Configuration Register 0x0000_0000
SCHI_TOIR0_0 0xFFF8_502C R/W Time out Initial Register 0 0x0000_0000
