W90P710CD/W90P710CDG
Publication Release Date: September 19, 2006
- 411 -
Revision B2
31
30
29
28
27
26
25
24
RESERVED
23
22
21
20
19
18
17
16
RESERVED
15
14
13
12
11
10
9
8
RESERVED DATAIN4[10:8]
7
6
5
4
3
2
1
0
DATAIN3[7:0]
BITS
DESCRIPTION
[31:11] RESERVED
-
[10:0]
DATAIN4
Port4 input data register
The DATAIN4 indicates the status of each GPIO52~GPIO59,
GPIO68 and GPIO69 pin regardless of its operation mode. The
reserved bits will be read as 0s
GPIO Port5 Configuration Register (GPIO_CFG5)
REGISTER ADDRESS
R/W
DESCRIPTION
RESET
VALUE
GPIO_CFG5 0xFFF8_3050
R/W
GPIO
port5 configuration register
0x0000_0000
31
30
29
28
27
26
25
24
RESERVED PT5CFG14 PT5CFG13 PT5CFG12
23
22
21
20
19
18
17
16
PT5CFG11 PT5CFG10 PT5CFG9 PT5CFG8
15
14
13
12
11
10
9
8
PT5CFG7 PT5CFG6 PT5CFG5 PT5CFG4
7
6
5
4
3
2
1
0
PT5CFG3 PT5CFG2 PT5CFG1 PT5CFG0
*In the following pin definition, mark with shading is default function.
11 10 01 00
PT5CFG0
Name Type Name Type Name Type
Name
Type
PORT5_0 RESERVED RESERVED TXD0 O GPIO5
I/O
