W90P710CD/W90P710CDG
Publication Release Date: September 19, 2006
- 455 -
Revision B2
Smart Card Host Test Mode Register (SCHI_TMR)
REGISTER ADDRESS R/W
DESCRIPTION
RESET
VALUE
SCHI_TMR0 0xFFF8_5020 R/W Test mode Register 0
0x0000_0000
SCHI_TMR1 0XFFF8_5820 R/W Test mode Register 1
0x0000_0000
This 8 bit register is added in order to allow better testability of the Smart Card host. Currently only bit 1 is
utilized. In the future, other bits can be used to program the host to improve testability on the testing
platform.
31
30
29
28
27
26
25
24
RESERVED
23
22
21
20
19
18
17
16
RESERVED
15
14
13
12
11
10
9
8
RESERVED
7
6
5
4
3
2
1
0
RESERVED SCRST_L
POWER_SEQ
_SKIP
