W90P710CD/W90P710CDG
- 476 -
BITS DESCRIPTIONS
[31:12] Reserved Reserved
[11] I2C_RxACK
Received Acknowledge From Slave (Read only)
This flag represents acknowledge from the addressed slave.
0 = Acknowledge received (ACK).
1 = Not acknowledge received (NACK).
[10] I2C_BUSY
I 2 C Bus Busy (Read only)
0 = After STOP signal detected.
1 = After START signal detected.
[9] I2C_AL
Arbitration Lost (Read only)
This bit is set when the I
2 C core lost arbitration. Arbitration is lost when:
A STOP signal is detected, but no requested.
The master drives SDA high, but SDA is low.
[8] I2C_TIP
Transfer In Progress (Read only)
0 = Transfer complete.
1 = Transferring data.
NOTE: When a transfer is in progress, you will not allow writing to any
register of the I
2 C master core except SWR.
[5:4] Tx_NUM
Transmit Byte Counts
These two bits represent how many bytes are remained to transmit.
When a byte has been transmitted, the Tx_NUM will decrease 1 until all
bytes are transmitted (Tx_NUM = 0x0) or NACK received from slave.
Then the interrupt signal will assert if IE was set.
0x0 = Only one byte is left for transmission.
0x1 = Two bytes are left to for transmission.
0x2 = Three bytes are left for transmission.
0x3 = Four bytes are left for transmission.
[3] Reserved Reserved
[2] IF
Interrupt Flag
The Interrupt Flag is set when:
Transfer has been completed.
Transfer has not been completed, but slave responded NACK (in multi-
byte transmit mode).
Arbitration is lost.
NOTE: This bit is read only, but can be cleared by writing 1 to this bit.
[1] IE
Interrupt Enable
0 = Disable I
2 C Interrupt.
1 = Enable I 2 C Interrupt.
[0] I2C_EN
I 2 C Core Enable
0 = Disable I 2 C core, serial bus outputs are controlled by SDW/SCW.
1 = Enable I 2 C core, serial bus outputs are controlled by I 2 C core.
